The operation video of this excavator is below the Descriptions ↓

Specifications

Tonnage (tons) 5

Machine working weight (kg) 5260

Bucket capacity (m³) 0.2

Performance

Slewing speed (rpm) 8.8

Traveling speed (km/h) 2.8/4.6

Gradability (%) 58

Bucket digging force (kN) 35.3

Power system

Engine model Yanmar 4TNV88

Rated power (kw/rpm) 29.3/2400

Displacement (L) 2.189

Cooling method Water cooling

Hydraulic system

Main pump type Variable pump × 2 + gear pump × 1

Oil capacity

Fuel tank (L) 53

Main transport dimensions

Total length for transport (mm) 5230

Total width for transport (mm) 1960

Total height for transport (mm) 2600

Full height of cab (mm) 2600

Total length of track (mm) 1970

Operating range

Maximum digging radius (mm) 5890

Maximum digging radius of parking surface (mm) 5750

Maximum digging depth (mm) 3590

Maximum digging height (mm) 5210

Maximum unloading height (mm) 3680

Maximum vertical digging depth (mm) 3160

Bulldozer blade width × height (mm) 1960 × 345‌

Descriptions

The Kobelco SK55 excavator is equipped with an advanced hydraulic system, has excellent digging capabilities and efficient operating speed, and can quickly complete various construction tasks. The excavator uses a low-speed high-torque engine, which can reduce fuel consumption and save energy while ensuring power.

Video:

Used excavator KOBELCO SK55SRX mini digger 5Ton backhoe good condition
